Guide: how to read a tire size

How to read a tire size

Updated November 17, 2026

Take 235/65R17 104H, the 2026 RAV4 LE's factory size: 235 mm wide, a sidewall 65% of that width, radial, a 17-inch wheel, load index 104 (900 kg, 1,984 lb per tire) and speed rating H (210 km/h, 130 mph). Everything you need to buy the right tire is printed on your door frame and on the tire itself.

235/65R17
235 mm wide, 65% sidewall, radial, 17-inch wheel
104H
Load index 104 = 900 kg (1,984 lb) a tire; H = 210 km/h (130 mph)

Pirelli's 235/65R17 104H size page and Toyota Canada's tire-size explainer, read Oct 29, 2026; 104 is our arithmetic from Toyota Canada's rule. See source

Close-up of tire tread on wet asphalt.
On this page
  1. 235/65R17 104H meaning, element by element
  2. Start with the placard, not the old tires
  3. Decoding 235/65R17 104H
  4. The date code: how old is the tire?
  5. UTQG grades: treadwear, traction, temperature
  6. Tire size questions
  7. Tires in the example size and others
  8. Sources

235/65R17 104H meaning, element by element

  • 235 is the section width: 'the width of the tire in millimetres' from sidewall to sidewall67.
  • 65 is the aspect ratio: the sidewall height as a percentage of the width, so about 153 mm here (our arithmetic)67.
  • R means radial construction; 17 is the wheel diameter in inches, so this tire fits a 17-inch wheel67.
  • 104 is the load index, 'the maximum weight that each wheel can support'6. Toyota Canada states index 100 as 800 kg (1,764 lb) and adds 25 kg (55 lb) per step, so 104 works out to 900 kg (1,984 lb) a tire (our arithmetic)7.
  • H is the speed rating, 'the maximum speed at which the tire is approved for use'6: 210 km/h (130 mph) in Toyota Canada's table7. Match or exceed the load index and speed rating on your placard.

Start with the placard, not the old tires

Federal rules require a "Tire and Loading Information" placard, normally on the driver's side B-pillar (the post you see when the driver's door is open). It must show the vehicle manufacturer's recommended cold tire inflation pressures and the tire size designation of the original equipment and spare tires1.

Use the placard rather than the tires on the car: a previous owner may have fitted a different size. If the placard is missing, the owner's manual or the automaker's specifications page for your trim (like the ones we use on our vehicle pages) lists the factory size.

Decoding 235/65R17 104H

On the tirePartMeaning
2356WidthSection width in millimetres, sidewall to sidewall
656Aspect ratioSidewall height as a percentage of the width
R6ConstructionRadial
176Rim diameterFits a 17-inch wheel
1047Load indexThe maximum weight each tire can support: 900 kg (1,984 lb), our arithmetic from Toyota Canada's 800 kg at index 100 plus 25 kg a step; match or exceed the placard
H7Speed ratingThe maximum speed the tire is approved for: 210 km/h (130 mph); match or exceed the placard
P or LT in frontService typeP-metric passenger tire or LT light truck tire; they carry different load ratings

The example size is the 2026 RAV4 LE's factory size4; SimpleTire listed the Bridgestone Alenza A/S Ultra in 235/65R17 104H at $205.96 per tire on October 2, 20265.

The date code: how old is the tire?

Every tire carries a tire identification number (TIN) beginning with "DOT". Its last four digits are the date code: the first two give the week and the last two the year of manufacture. Federal rules give the example 0109, meaning the first full calendar week of 20092.

Check the date code on tires when they arrive. A new-looking tire can have sat in a warehouse; ask the seller about its policy on older stock before you mount them.

UTQG grades: treadwear, traction, temperature

Most passenger tires carry three Uniform Tire Quality Grades3.

  • Treadwear

    Comparative: a tire graded 150 would wear one and a half times as well on the government course as one graded 1003. Not a mileage figure.

  • Traction

    AA, A, B, C, from highest: the ability to stop on wet pavement3.

  • Temperature

    A, B, C: resistance to generating heat and the ability to shed it3.

Deep-tread winter-type snow tires, space-saver spares and tires for rims of 12 inches or less are excluded from these grades3. For mileage, the maker's tread life warranty is the more direct number (see tread life warranties compared).

Tire size questions

Can I fit a different size than the placard?

Sometimes, with the right wheels and a matching overall diameter and load rating, but it can affect the speedometer, stability systems and clearance. Ask a tire professional; this guide is not a fitment recommendation.

Where is the date code?

At the end of the tire identification number that starts with "DOT" on the sidewall: week, then year2.

Tires in the example size and others

Good for where the size is printed, explained by the maker

Pirelli Scorpion AS Plus 3

See it on PirelliOpens Pirelli's site. Not a referral link.

Good for a size and vehicle chooser on the maker's page

Michelin Defender2

See it on MichelinOpens Michelin's site. Not a referral link.

Sources

  1. 49 CFR 571.110, tire selection and rims (placard, S4.3)Legal Information Institute, Cornell Law School, read Oct 2, 2026
  2. 49 CFR 574.5, tire identification requirementsLegal Information Institute, Cornell Law School, read Oct 2, 2026
  3. 49 CFR 575.104, uniform tire quality grading standardsLegal Information Institute, Cornell Law School, read Oct 2, 2026
  4. 2026 Toyota RAV4 tire sizes by trim (tire selector)Michelin North America, read Oct 10, 2026
  5. Bridgestone Alenza A/S Ultra sizes and pricesSimpleTire, read Oct 2, 2026
  6. 235/65R17 104H tire size page (what each element means)Pirelli, read Oct 29, 2026
  7. What Do Those Numbers on Your Tires Mean? (May 27, 2019; load index and speed rating values)Toyota Canada, read Oct 29, 2026
